IMG Stageline ECM-302 boundary microphones


Black or white surface mounting boundary microphone




IMG Stageline ECM-302 boundary condenser microphones for surface fixing on any wall or other boundary surface. These microphones require a 9 to 48v phantom power supply supplied by your mixer or amplifier or by a stand alone power supply such as the EMA-200

  • Integrated electronics for use with phantom power 9-48V DC current
  • Transformer-balanced AF output
  • With 6m connection cable 3-pole mini XLR/XLR
  • Available colours: Black (ECM-302B) and white (ECM-302B/WS)
  • Type: boundary microphone
  • Transmission method: cable
  • Polar pattern: semi-cardioid
  • System: electret
  • Audio frequency range: 30-20,000 Hz
  • Nominal impedance: 250 Ω
  • Sensitivity: 22 mV/Pa
  • Maximum sound pressure: 140 dB
  • Power supply: DC current  17-48 V, phantom power
  • Admiss. ambient temp.: 0-40 °C
  • Dimensions: Ø 120 mm x 22 mm
  • Weight: 350 g
  • Cable: 6 m
  • Connection: 3-pole mini XLR/XLR


IMG Stageline

Additional information

Weight 0.35 kg
Dimensions 12 x 12 x 2.2 cm

Black, White
