Fonestar MX-867RU Zone Mixer

Description

Fonestar MX-867RU 4-zone mixer/preamplifier with MP3 player and FM tuner

Mixer/preamplifier with 5-channel audio matrix assignable to 4 output zones with independent volume control. USB/SD player with FM radio tuner. Audio distribution in multi-zone installations with different music programmes. Independent output remote volume control.

• Features:
  • Mixer/preamplifier
  • Microphone input with paging priority
  • Matrix allocation of 5 input channels to 4 output zones
  • USB/SD player
  • Digital FM radio tuner – PLEASE NOTE that for good FM reception an external FM aerial will be required
  • 4 speaker zones with independent volume control
  • Remote zone volume control
  • Phantom power supply
• Inputs:
  • 1 balanced microphone, 6.3 mm stereo jack, 12 mV RMS
  • 1 balanced mic., combo (XLR and 6.3 mm jack), 12 mV RMS
  • 2 balanced mics./lines combo (XLR and 6.3 mm jack) adjustable, 12 mV RMS and 640 mV RMS
  • 1 stereo aux, 2 x RCA, 230 mV RMS
  • 1 stereo aux, 3.5 m jack, 450 mV RMS
• Outputs:
  • 4 balanced zones, XLR, 2.5 V RMS
  • Remote volume control for the zones
  • 1 stereo monitor, 6.3 mm jack, 1 V RMS
• Controls:
  • 4 micro allocation switches for zones 1 to 4
  • Inputs 1 to 4: volume control
  • Inputs 2 and 3: gain control
  • Zones 1 to 4: volume control
  • Monitor: volume control and zone selection
  • USB/SD player
  • FM tuner
• Frequency Response: 20-20,000 Hz
• Distortion: Harmonic: < 0.2 % to 1 kHz
• S/N Ratio:
  • Microphones > 65 dB
  • Aux/Line > 80 dB
• Phantom Power: 48 V in mics. 2 and 3, selectable
• Priority: Mic. 1 input level priority, selectable
• Power Supply: 230/115 V AC, 9 W
• Dimensions: 483 x 44.5 x 200 mm depth. 1 U 19″ rack
• Weight: 3.15 kg
