Description
JTS CS-1CH chairperson’s conference microphone
Part of the CS-1 Conference system. The CS-1 CH chairman unit has priority over the delegate units. There is a priority key which can either mute or turn off all delegate units, or cancel all applying. The chairman unit has the right to accept or refuse applying. Requires an optional Control unit and optional delegate units for a complete system.
The chairman unit not only provides the same function as the delegate unit, but also supports the addition of a “Priority button”, that enables the chairman to control the discussion by temporary or permanently overriding and deactivating all active microphones of the delegate units.
Professional conference sound system for council chambers, boardrooms and meeting venues control unit requires 1 chair person microphone and up to 49 delegate units – delegate microphones can be converted to passive or press / reporter units by removing the microphone stem.
The microphone station for the chairperson CS-1CH and the microphone station for conference delegates CS-1DU together form a conference discussion system with extensive configuration facilities for maximum flexibility.
- Back electret cartridge of cardioid characteristic optimised for voice transmissions
- Built-in speaker and connection for optional headphones
- Convenient operation due to large function buttons
- Status displays on the microphone and desktop station
- Priority button with chime
- System: back electret
- Audio frequency range: 50-18,000 Hz
- Power supply: via control unit CS-1CU
- Gooseneck length: 400 mm
- Dimensions: 115 x 65 x 170 mm (console housing)
- Weight: 1.1 kg
- Connection: 2 x 3.5 mm jack, 1 x 2 m connection cable with 7-pole DIN plug, 1 x 7-pole DIN jack
See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
