100v Line

Monacor PA-948 Mixer Amplifier

SKU: PA-948

£675.00 + VAT    £810.00 incl. VAT

480w into 100v line or 4-8Ω low impedance mixer amplifier

In stock

100V Line

PDF

Description

Monacor PA-948 480w Mono PA mixing amplifier

  • 1 x 480 W
  • Fan cooled
  • 4 balanced microphone inputs with selectable priority
  • 4 line inputs
  • Speaker outputs via screw terminals
  • Balanced line output
  • Record output
  • Insert facility, e.g. for effect units, equalizers, feedback controllers
  • 2-tone or 4-tone chime, can be activated externally
  • Input level control and output level control
  • 2-way tone control for the output
  • Switchable 48 V phantom power for microphone inputs
  • Temperature-controlled fan
  • Mains operation or 24 V emergency power operation
  • Removable mounting brackets
  • Input channels: 5
  • Power rating: 480 W
  • Peak music power output (PMAX): 680 W
  • Inputs: 2.5-100 mV (mic), 350 mV (line)
  • Frequency range: 50-16,000 Hz, ± 3 dB
  • Equalizer bass: ± 10 dB/100 Hz
  • Equalizer treble: ± 10 dB/10 kHz
  • S/N ratio: > 75 dB
  • THD: < 0.1%
  • Power supply: AC 230 V/50 Hz/1,090 VA,
  • Operating voltage: DC 24 V, 27 A
  • Admiss. ambient temp: 0-40 °C
  • Dimensions: 482 x 137 x 395 mm, 3 RS
  • Weight: 22.6 kg
  • Connections: 4 x XLR (mic), 4 x RCA L/R (line), 1 x XLR (line out), 1 x RCA L/R (line out), screw terminals (speakers)

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

Additional information

Weight22.6 kg
Dimensions39.5 × 48.2 × 13.7 cm
Zones

1

Connection

3 Pin XLR (Female), 3 Pin XLR (Male), RCA Phono, Screw Terminals

Condition

New

Colour

Black

Brand

Monacor

Monacor is one of Europe’s largest distributors of PA sound and lighting equipment. Monacor understand public address and sound reinforcement comprehensively and offer a diverse range of products for all commercial sound and lighting needs. In addition to classic sound systems for sound reinforcement such as music systems, amplifiers, loudspeakers, and mixing desks, the full portfolio also includes complex conference systems, accessories for voice alarm or mobile amplifier systems, as well as induction loop sound systems, 100v line PA and megaphones. Whether you want to bring sound to one person or thousands: Monacor has the right solution for you. Our professional and commercial sound products, wireless microphones and induction loops are carefully chosen for sale on our website by Sound Services – not everything from every manufacturer is there. Based on feedback, customer reviews and our own observations we list items that are popular, reliable and good value for money. If there are products not shown on our website that you feel we may be able to quote for, please just ask!
