Description
Adastra BC5V series 30w black or white 100v line indoor moulded wall mounted or free standing cabinet speaker
A range of indoor speakers, with ABS enclosures and a sturdy metal grille. Suitable for free standing or wall mounting via adjustable fixing bracket. The trapezoidal design allows for the enclosures to be mounted neatly into corners, making them ideal for most applications.
- Supplied singly
- 2 way speaker system with crossover network
- Rotary selector switch for 100V line tappings or 8 Ohms operation
- Wall mounting bracket supplied
- Alternative M6 threaded mounting points
- Spring terminal connection
- Available in black and white – see option
- Woofer: 130mmØ (5.25”) reinforced paper cone
- Tweeter: 25mm (1”) balanced dome
- Frequency response: 100Hz – 20kHz
- Power max. : 8 Ohms: 90W
- Power rms : 8 Ohms: 45W
- SPL @ 1W/1m: 89dB
- Tappings: 30W, 20W, 10W, 5W + 8 Ohms
- Impedance : 100V: 333, 500, 1k, 2k Ohms
- Dimensions: 180 x 235 x 175mm
- Weight: 2.38kg
See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
