Designed to meet the needs of professional vocalists, musicians and other PA users, the Performer-12 system has a range of features beyond those found on other portable speakers. Built into a robust moulded cabinet with integral telescopic trolley handle and rolling wheels, the internal 2-way speaker set is powered by a powerful class-AB amplifier circuit and controlled from a comprehensive mixer section on the rear panel. Powered by an internal rechargeable battery, or from mains or 12V power input to cover a range of possible scenarios. On top of the cabinet is a flip-top compartment housing 2 rechargeable UHF wireless handheld microphones. These can be recharged via a USB power output on the rear panel using the cable provided. Alternatively, 2 wired microphones may be connected via combo jack/XLR sockets. Mic1 and Mic2 have a shared 2-band EQ and are served by a 16 program DSP effect section, each with a programmable parameter adjustment for genuine echo and reverb effects. A separate jack/XLR socket input for guitar also has independent 2-band EQ and level control. Playback of recorded tracks is served by an onboard audio player with mp3 playback from USB flash drive or SD card or wireless playback from a smart phone via Bluetooth. Alternatively, a line input on RCA or XLR can be used for playback material from an external source. Overall, the Performer-12 has a comprehensive array of functions for almost any mobile or temporary PA application.

• Mains, low voltage or rechargeable power options
• Integral trolley for easy portability
• 2 x rechargeable UHF microphones
• Flip-top compartment for UHF mics
• USB/SD playback and Bluetooth connectivity
• Power supply 230Vac, 50Hz (IEC), 12Vdc or internal battery
• Battery 12V 9Ah lead-acid
• Battery life 5-7 hours
• Charge time 3-4 hours
• Woofer 300mmØ (12″)
• Tweeter 25mm (1″) titanium diaphragm
• Output power max. 200W
• Wireless microphone frequencies 863.1 – 864.9MHz
• Effects 16 program DSP
• Audio source USB/SD mp3 player, Bluetooth receiver
• SPL max. 119dB
• Sensitivity 96dB
• Frequency response 55Hz – 18kHz
• Dimensions 540 x 350 x 310mm
• Weight 17.0kg

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

Not quite right for you?
Ask us to quote a custom PA sound system

The post QTX PERFORMER-12 Portable 200W All-in-One PA System appeared first on Sound Services.

System includes:

• Stereo 300+300W power amplifier
• Media mixer with Bluetooth
• Dual licence-free handheld wireless microphone system
• 2U rack drawer for convenient microphone and accessory storage
• 6U wall-mount rack – rack fixings included
• 1U blanking panel for aesthetic tidiness
• Four high power music cabinet speakers and wall-mount brackets
• All required cables and connectors

Amplifier

Stereo power amplifier in a lightweight 1U rack-mountable housing. Class-D circuit architecture efficiently converts power into impactful audio for driving medium to large speaker cabinets. Custom cool guide technology ensures consistent and reliable operation and an inbuilt limiter circuit engages at peak output to prevent speaker overload. Options for parallel and bridge mode with selectable input levels and 75Hz low cut filter allow for different configurations to handle even the most demanding of sound reinforcement duties.

Media Mixer

Rack-mountable 1U mixer with built-in media player and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo record output. Media player operating modes include 3.5mm Aux input, USB audio player, FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right outputs are fed to XLR with an additional mono summed output on 6.3 jack. Versatile yet easy to use as a main mixer for background music, public address and house PA systems.

Wireless Microphone Set

DTM 800H twin wireless microphone system with 2 x handheld transmitters on Channel 70 (863-865 MHz) with 20 selectable frequencies these systems utilise a true diversity, full width 19″ rack mountable receiver for the ultimate in RF stability. Outstanding vocal reproduction and stable wireless connectivity allow freedom of movement on stage. These systems offer crystal clear sound reproduction and rock solid reliability. Metal bodied handheld transmitters feature ergonomic design with a rugged housing to stand up to the rigours of the road.

Speakers

Premium full-range passive speaker cabinets with a polyurea coated wooden enclosure and powder-coated steel grille. A high power-handling main driver and efficient titanium diaphragm HF compression driver combine with the tuned enclosure to deliver a balanced output of all frequencies. The rear panel has 2 parallel inputs for Speakon connection, also enabling linking onto additional speakers. Each cabinet has 2 side handles and a 35mm pole-mount socket for stand mounting. The rear of the cabinet has 2 different bevels for angled placement at ground level or for suspended arraying, multiple M8 flying points are inset on each cabinet. Recommended for use with Citronic PLX, D and H series amplifiers for a wide range of professional high power sound reinforcement situations.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Complete Village Hall Sound System appeared first on Sound Services.

System includes:

• Stereo 150+150W power amplifier
• Media mixer with Bluetooth
• Dual licence-free handheld wireless microphone system
• 2U rack drawer for convenient microphone and accessory storage
• 6U wall-mount rack – rack fixings included
• 1U blanking panel for aesthetic tidiness
• Two high power music cabinet speakers and wall-mount brackets
• All required cables and connectors

Amplifier

Stereo power amplifier in a lightweight 1U rack-mountable housing. Class-D circuit architecture efficiently converts power into impactful audio for driving medium to large speaker cabinets. Custom cool guide technology ensures consistent and reliable operation and an inbuilt limiter circuit engages at peak output to prevent speaker overload. Options for parallel and bridge mode with selectable input levels and 75Hz low cut filter allow for different configurations to handle even the most demanding of sound reinforcement duties.

Media Mixer

Rack-mountable 1U mixer with built-in media player and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo record output. Media player operating modes include 3.5mm Aux input, USB audio player, FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right outputs are fed to XLR with an additional mono summed output on 6.3 jack. Versatile yet easy to use as a main mixer for background music, public address and house PA systems.

Wireless Microphone Set

DTM 800H twin wireless microphone system with 2 x handheld transmitters on Channel 70 (863-865 MHz) with 20 selectable frequencies these systems utilise a true diversity, full width 19″ rack mountable receiver for the ultimate in RF stability. Outstanding vocal reproduction and stable wireless connectivity allow freedom of movement on stage. These systems offer crystal clear sound reproduction and rock solid reliability. Metal bodied handheld transmitters feature ergonomic design with a rugged housing to stand up to the rigours of the road.

Speakers

Premium full-range passive speaker cabinets with a polyurea coated wooden enclosure and powder-coated steel grille. A high power-handling main driver and efficient titanium diaphragm HF compression driver combine with the tuned enclosure to deliver a balanced output of all frequencies. The rear panel has 2 parallel inputs for Speakon connection, also enabling linking onto additional speakers. Each cabinet has 2 side handles and a 35mm pole-mount socket for stand mounting. The rear of the cabinet has 2 different bevels for angled placement at ground level or for suspended arraying, multiple M8 flying points are inset on each cabinet. Recommended for use with Citronic PLX, D and H series amplifiers for a wide range of professional high power sound reinforcement situations.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Complete Village Hall Sound System appeared first on Sound Services.

System includes:

• Stereo 300+300W power amplifier
• Media mixer with Bluetooth
• Dual licence-free handheld wireless microphone system
• 2U rack drawer for convenient microphone and accessory storage
• 6U wall-mount rack – rack fixings included
• 1U blanking panel for aesthetic tidiness
• Four high power music cabinet speakers and wall-mount brackets
• All required cables and connectors

Amplifier

Stereo power amplifier in a lightweight 1U rack-mountable housing. Class-D circuit architecture efficiently converts power into impactful audio for driving medium to large speaker cabinets. Custom cool guide technology ensures consistent and reliable operation and an inbuilt limiter circuit engages at peak output to prevent speaker overload. Options for parallel and bridge mode with selectable input levels and 75Hz low cut filter allow for different configurations to handle even the most demanding of sound reinforcement duties.

Media Mixer

Rack-mountable 1U mixer with built-in media player and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo record output. Media player operating modes include 3.5mm Aux input, USB audio player, FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right outputs are fed to XLR with an additional mono summed output on 6.3 jack. Versatile yet easy to use as a main mixer for background music, public address and house PA systems.

Wireless Microphone Set

DTM 800H twin wireless microphone system with 2 x handheld transmitters on Channel 70 (863-865 MHz) with 20 selectable frequencies these systems utilise a true diversity, full width 19″ rack mountable receiver for the ultimate in RF stability. Outstanding vocal reproduction and stable wireless connectivity allow freedom of movement on stage. These systems offer crystal clear sound reproduction and rock solid reliability. Metal bodied handheld transmitters feature ergonomic design with a rugged housing to stand up to the rigours of the road.

Speakers

Full-range speaker cabinets housed in a compact and lightweight moulded Polypropylene (PP) enclosure. Custom designed low frequency woofers are paired with titanium compression drivers for a powerful yet balanced sound delivery. Each cabinet is fitted with top and side carrying handles and a 35mm pole mount socket. Connection from an amplifier is via Speakon lead to either of the 2 sockets on the rear panel. Compact, lightweight and yet very capable sound reinforcement cabinets.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Complete Village Hall Sound System appeared first on Sound Services.

System includes:

• Stereo 150+150W power amplifier
• Media mixer with Bluetooth
• Dual licence-free handheld wireless microphone system
• 2U rack drawer for convenient microphone and accessory storage
• 6U wall-mount rack – rack fixings included
• 1U blanking panel for aesthetic tidiness
• Two high power music cabinet speakers and wall-mount brackets
• All required cables and connectors

Amplifier

Stereo power amplifier in a lightweight 1U rack-mountable housing. Class-D circuit architecture efficiently converts power into impactful audio for driving medium to large speaker cabinets. Custom cool guide technology ensures consistent and reliable operation and an inbuilt limiter circuit engages at peak output to prevent speaker overload. Options for parallel and bridge mode with selectable input levels and 75Hz low cut filter allow for different configurations to handle even the most demanding of sound reinforcement duties.

Media Mixer

Rack-mountable 1U mixer with built-in media player and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo record output. Media player operating modes include 3.5mm Aux input, USB audio player, FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right outputs are fed to XLR with an additional mono summed output on 6.3 jack. Versatile yet easy to use as a main mixer for background music, public address and house PA systems.

Wireless Microphone Set

DTM 800H twin wireless microphone system with 2 x handheld transmitters on Channel 70 (863-865 MHz) with 20 selectable frequencies these systems utilise a true diversity, full width 19″ rack mountable receiver for the ultimate in RF stability. Outstanding vocal reproduction and stable wireless connectivity allow freedom of movement on stage. These systems offer crystal clear sound reproduction and rock solid reliability. Metal bodied handheld transmitters feature ergonomic design with a rugged housing to stand up to the rigours of the road.

Speakers

Full-range speaker cabinets housed in a compact and lightweight moulded Polypropylene (PP) enclosure. Custom designed low frequency woofers are paired with titanium compression drivers for a powerful yet balanced sound delivery. Each cabinet is fitted with top and side carrying handles and a 35mm pole mount socket. Connection from an amplifier is via Speakon lead to either of the 2 sockets on the rear panel. Compact, lightweight and yet very capable sound reinforcement cabinets.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Complete Village Hall Sound System appeared first on Sound Services.

Whether you run a Club, Bar, Restaurant, Retail Store, Church, or other Place of Worship, our annual service agreements are designed to offer excellent value and total peace of mind.

Your Annual Service Package Includes:

• A dedicated engineer – personal support from a named Sound Services technician who knows your system inside and out
• Full system inspection – including electrical PAT testing, inventory checks, and a written report with certification at the start of your contract
• Reliable performance – we keep your PA system running as expected, helping you avoid last-minute failures or poor audio quality
• Ongoing advice and support – phone and email assistance during working hours, with no hidden fees
• Priority attention when needed – fast response, including out-of-hours support (evenings/weekends) depending on your contract
• Loan equipment – temporary gear supplied at no extra cost if your equipment needs repair or replacement
• Preferential rates – discounted prices on replacement parts and labour when needed
• Regular on-site checks – scheduled visits to ensure safety, stability, and ease of use, including PAT testing and written certification
• Our service contracts offer exceptional value by combining technical expertise, responsive support, and cost-saving benefits — all from a trusted local provider.

If you’re located within 25 miles of Fleet, Hampshire, get in touch today on 01252 751272 or email us to discuss your custom service contract proposal. Let Sound Services keep your audio systems running smoothly, so you can focus on what matters most.

The post Peace of Mind Service Contract for your PA Sound System from Sound Services appeared first on Sound Services.

System includes:

• 1 x PROX-240Z 240W 100V line 4-zone mixer amplifier with Bluetooth and MP3 player
• Up to 30 x SKY-5T 12W 5″ 100V line low profile ceiling speakers
• 1 x 3.5mm jack auxiliary lead
• 2 x 100m reels of 6A speaker cable

Amplifier

Fonestar PROX-240Z 240W 100V line 4-zone mixer amplifier with Bluetooth and MP3 player

Public Address Amplifier with Bluetooth®/USB/FM Player and Speaker Zone Selector.

• The best tool for sound reinforcement in any space
• Reliable for long working hours
• Distributed audio for public address installations with 100V speakers, also featuring a low-impedance output
• Versatile player for background music. Bluetooth, FM, and USB memory player. With an automatic playback function upon power-up
• Includes 4 zone outputs with volume control for different music levels per zone
• Easy-to-use interface with a modern and discreet design
• A solution that adapts to any budget
• Secure and durable connections with low maintenance
• Can be used as a tabletop unit or installed in a rack

Perfect for public address and background music systems with 100V line or low-impedance speakers. Commercial spaces, educational centers, monuments, exhibitions, bars, restaurants, etc.

• Features:
  • Public address amplifier
  • Bluetooth/USB/FM player
  • Microphone input with mix, gain and priority level control
  • Input priorities by signal level
  • Tone controls
  • 100 V and 4 Ω outputs
  • 4 outputs zones with volume control and Off
• Power: 240 W RMS
• Frequency response: 40-20,000 Hz (-10 dB)
• Distortion: THD+N: < 1% @ 1 kHz
• S/N ratio: >77 dB
• Protections: Overcurrent, DC and short-circuit at the output
• Inputs:
  • CH 1 balanced mic/line with 48V Phantom, Combo (XLR + 6.3 mm) and euroblock
  • CH 2, 3 and 4 balanced mic/line with 48V Phantom. Euroblock connector
  • Mic signal level: 6 mV RMS (-44 dBV) / 600 Ω
  • Line signal level: 250 mV RMS (-12 dBV) / 100k Ω
  • 2 x AUX. 2 x RCA and euroblock connector. Signal level 300 mV RMS (-10 dBV) / 47,000 Ω
  • 1 x emergency. Euroblock connector. Speaker line signal level 100 V
  • 1 x Mute (Emergency Priority) by contact closure. Euroblock connector
• Outputs:
  • 1 x line. 2 x RCA connector. Signal level 1.25 mV RMS (+2 dBV)
  • 100 V or 4 Ω speaker output, or 4 x 100 V speaker zones with 5-position volume selector and OFF (max. 120 W RMS per zone). Connector screw terminals
• Impedance: 4 Ω and 100 V (42Ω) line
• Functions:
  • Priority of entries (in order of attenuation):
    • Emergency entry 100
    • Mute by closing contacts
    • Channel 1 with selectable signal level shared CH 1-2-3-4 (VOX)
    • Channels 2 | 3 | 4 with selectable signal level shared CH 1-2-3-4 (VOX)
    • Auxiliary Inputs | Player
  • Light indicators for ignition, protection, signal peak and output signal
  • Cooling by forced ventilation controlled by temperature
• Player: Bluetooth/USB/FM player for ambient music playback
  • MP3 and WAV files supported
  • Maximum USB memory capacity 64 GB
  • Autoplay, starts playback automatically when switched on
  • Playback mode memory (random, repeat)
• CONTROLS:
  • Microphone volume
  • Mic/line/phantom switch
  • Master volume
  • Auxiliary input selector or player
  • Zone volume
  • Tone: bass and treble (±10 dB 100 Hz and 10k Hz).
  • Microphone gain
  • Priority activation signal level (VOX)
• Temperature: Operation: 0º ~ 40ºC
• Maximum humidity: 95%
• Power supply: 230/115 V AC, 50-60 Hz, 480 W, Fuse AC 230 V 4 A / 115 V 8 A
• Dimensions: 433 x 89 x 360 mm depth. 2 U 19” rack
• Weight: 11.5 kg
• Accessories:
  • FM antenna
  • Bluetooth antenna
  • Power cable
  • Rack mounts

Speakers

Fonestar SKY-5T 12W 5″ 100V line low profile ceiling speaker

Design by Fonestar products are the result of in-depth research and active listening to our customers, turning their needs into competitive solutions. Stylish design and acoustic versatility in a 5‘’ ceiling speaker. The SKY-5T is a 100 V line transformer ceiling loudspeaker designed to combine aesthetics and functionality in professional sound system engineering and installation projects. Its frameless, low-profile grille in rust-resistant aluminium provides a discreet, modern finish. In addition, it is detachable, twist-lockable and customisable, allowing the logo to be removed and painted to suit the environment.

This loudspeaker is designed to meet the needs of demanding installers and technical projects thanks to advanced features

• Efficient installation: quick-connect terminals for 0.4 to 4 mm² cables, anti-fall system and safety hook for easy mounting in ceilings up to 30 mm thick
• Guaranteed durability: high-strength materials, such as UV-protected ABS and painted aluminium grille, meet dust, water and neutral salt spray resistance standards (IP-44)
• Excellent acoustic performance: wide response range (55-20,000 Hz), optimised coverage angles and sound pressure of up to 98 dB, ideal for indoor and outdoor PA projects

The SKY-5T stands out for its combination of performance, reliability and design

• High-quality sound thanks to its 5‘’ dual-cone polypropylene diaphragm and adjustable impedance settings (833 Ω to 3.333 Ω)
• Application flexibility with support for challenging environments (-20 °C to 70 °C, 95 % max. humidity)
• Easy maintenance and customisation, suitable for multiple environments, from offices to commercial spaces
• The SKY-5T is the perfect choice for those seeking quality, style, and functionality in in-ceiling loudspeaker solutions

Specifications

• Features:
  • Ceiling loudspeaker with 100 V line transformer
  • Low profile frameless grille, constructed from rust resistant aluminium. Detachable, turn-lockable grille. The logo can be removed and painted
  • Fast connection terminals and high conductivity
  • Anti-fall system for installation assistance
  • Hook for safety cable
  • Stable, worm-gear ceiling brackets
  • Protection against dust and water
• Power:
  • 12 W RMS
  • 16 W MAX.
• Speaker: 5” polypropylene double cone diaphragm
• Frequency response:
  • 55-20,000 Hz @ -10 dB
  • 70-20,000 Hz @ -3 dB
• Impedance:
  • 12 W RMS@100 V (833 Ω)
  • 6 W RMS@100 V/70 V (1.666 Ω/816 Ω)
  • 3 W RMS@100 V/70 V (3.333 Ω/1,633 Ω)
  • 1.5 W RMS@70 V (3.266 Ω)
• Sensitivity: 85 dB @ 1 W/1 m
• Sound pressure:
  • 97 dB @ max. W/1m Continuous
  • 98 dB @ max. W/1m Peak
• Dispersion angle: 90º@1kHz (- 6 dB)
• Protections:
  • IP44 in compliance with IEC 60529
  • EN ISO 9227:2006 Neutral Salt Spray Test
• Material:
  • ABS (UV resistant)
  • Liquid paint aluminium grille
• Connectors:
  • Highly conductive quick-connect terminals
  • For 0.4 ~ 4 mm² cross section cable
• Operation temperature: -20ºC ~ 70°C (48 h)
• Storage temperature: 10ºC ~ 40°C
• Maximum humidity: 95%
• Colour: White (RAL 9003)
• Dimensions:
  • Total loudspeaker: 214 mm Ø x 85 mm height
  • Grille section: 5 mm
  • Recessed height: 80 mm
  • Installation hole: 180 mm Ø
  • Maximum ceiling thickness: 30 mm
• Weight: 0.8 kg
• Accessories : Installation template

Speaker cable

Mercury oval 100m 6A 100v line speaker cable

Available in:

• Black 100m (804.314)
• White 100m (804.311)

Oval profile mains electric cable. Flexible PVC sheath for use in light electrical applications. BSI approved to BS6500, VDE approved.

• CSA: 0.75mm²
• Strands: 2 x 24/0.2mmØ
• Cable dims: 3.6 x 5.9mm
• Current: 6A max.
• Length: 100m

Product styles may vary.

Each speaker must be set to a maximum of 6W if connecting more than 18 speakers. Exceeding this will overload the amplifier. The system’s total capacity is 240W, with a maximum of 120W per zone.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Fonestar Background Music Sound System appeared first on Sound Services.

System includes:

• 1 x PROX-240Z 240W 100V line 4-zone mixer amplifier with Bluetooth and MP3 player
• 15 x SONORA-4T series black or white high power weatherproof 4″ 30W 100v line or 8Ω cabinet speakers
• 1 x 3.5mm jack auxiliary lead
• 2 x 100m reels of 6A speaker cable

Amplifier

Fonestar PROX-240Z 240W 100V line 4-zone mixer amplifier with Bluetooth and MP3 player

Public Address Amplifier with Bluetooth®/USB/FM Player and Speaker Zone Selector.

• The best tool for sound reinforcement in any space
• Reliable for long working hours
• Distributed audio for public address installations with 100V speakers, also featuring a low-impedance output
• Versatile player for background music. Bluetooth, FM, and USB memory player. With an automatic playback function upon power-up
• Includes 4 zone outputs with volume control for different music levels per zone
• Easy-to-use interface with a modern and discreet design
• A solution that adapts to any budget
• Secure and durable connections with low maintenance
• Can be used as a tabletop unit or installed in a rack

Perfect for public address and background music systems with 100V line or low-impedance speakers. Commercial spaces, educational centers, monuments, exhibitions, bars, restaurants, etc.

• Features:
  • Public address amplifier
  • Bluetooth/USB/FM player
  • Microphone input with mix, gain and priority level control
  • Input priorities by signal level
  • Tone controls
  • 100 V and 4 Ω outputs
  • 4 outputs zones with volume control and Off
• Power: 240 W RMS
• Frequency response: 40-20,000 Hz (-10 dB)
• Distortion: THD+N: < 1% @ 1 kHz
• S/N ratio: >77 dB
• Protections: Overcurrent, DC and short-circuit at the output
• Inputs:
  • CH 1 balanced mic/line with 48V Phantom, Combo (XLR + 6.3 mm) and euroblock
  • CH 2, 3 and 4 balanced mic/line with 48V Phantom. Euroblock connector
  • Mic signal level: 6 mV RMS (-44 dBV) / 600 Ω
  • Line signal level: 250 mV RMS (-12 dBV) / 100k Ω
  • 2 x AUX. 2 x RCA and euroblock connector. Signal level 300 mV RMS (-10 dBV) / 47,000 Ω
  • 1 x emergency. Euroblock connector. Speaker line signal level 100 V
  • 1 x Mute (Emergency Priority) by contact closure. Euroblock connector
• Outputs:
  • 1 x line. 2 x RCA connector. Signal level 1.25 mV RMS (+2 dBV)
  • 100 V or 4 Ω speaker output, or 4 x 100 V speaker zones with 5-position volume selector and OFF (max. 120 W RMS per zone). Connector screw terminals
• Impedance: 4 Ω and 100 V (42Ω) line
• Functions:
  • Priority of entries (in order of attenuation):
    • Emergency entry 100
    • Mute by closing contacts
    • Channel 1 with selectable signal level shared CH 1-2-3-4 (VOX)
    • Channels 2 | 3 | 4 with selectable signal level shared CH 1-2-3-4 (VOX)
    • Auxiliary Inputs | Player
  • Light indicators for ignition, protection, signal peak and output signal
  • Cooling by forced ventilation controlled by temperature
• Player: Bluetooth/USB/FM player for ambient music playback
  • MP3 and WAV files supported
  • Maximum USB memory capacity 64 GB
  • Autoplay, starts playback automatically when switched on
  • Playback mode memory (random, repeat)
• CONTROLS:
  • Microphone volume
  • Mic/line/phantom switch
  • Master volume
  • Auxiliary input selector or player
  • Zone volume
  • Tone: bass and treble (±10 dB 100 Hz and 10k Hz).
  • Microphone gain
  • Priority activation signal level (VOX)
• Temperature: Operation: 0º ~ 40ºC
• Maximum humidity: 95%
• Power supply: 230/115 V AC, 50-60 Hz, 480 W, Fuse AC 230 V 4 A / 115 V 8 A
• Dimensions: 433 x 89 x 360 mm depth. 2 U 19” rack
• Weight: 11.5 kg
• Accessories:
  • FM antenna
  • Bluetooth antenna
  • Power cable
  • Rack mounts

Speakers

Fonestar SONORA-4T series black or white high power weatherproof 4″ 30W 100v line or 8Ω cabinet speaker

Sound reinforcement loudspeaker with 100 V line transformer and low impedance. Based on our extensive experience in the sound sector, FONESTAR has created SONORA. SONORA is a series of speakers specially designed for PA, musical and background sound applications. Its excellent finish and elegant design allow perfect integration in any space. They are fully prepared for outdoor use as they feature aluminium grille and protection against water (IP-66) and marine environments. Besides, SONORA delivers high sound quality with clear, distortion-free sound. They include all the necessary accessories for easy and quick installation: weatherproofed adjustable fixing mount, stainless steel screws and steel safety cable. For public address and ambient sound applications in public places such as restaurants, cafés, supermarkets, shopping centres, etc.

• Features:
  • Low-impedance loudspeaker with 100 V line transformer
  • Suitable for outdoor use, waterproof and rustproof materials
• Power: 60 W max., 30 W RMS
• Speakers:
  • 1 x 5 ¼” polypropylene woofer
  • 1 x 1″ tweeter
• Frequency Response: 80-20,000 Hz
• Impedance:
  • 30 W RMS@100 V (333 Ω)
  • 15 W RMS@100 V/70 V (667 Ω/326 Ω)
  • 7’5 W RMS@100 V / 70 V(1.333 Ω/ 653 Ω)
  • 3’75 W RMS@100 V / 70 V(2.667 Ω/ 1.306 Ω)
  • 1’9 W RMS@70 V (2.579 Ω)
  • Low Z: 8 Ω
• Sensitivity: 84.9 dB @ 1 W/1 m
• Maximum SPL: 97.6 dB @ max. W/1 m
• Coverage Angle: 145º H x 130º V @1kHz (-6 dB)
• Protections:
  • IP-66 in compliance with EN 60529
  • IEC 60068-2-11 Enviromental Test (Salt mist)
• Material:
  • ABS
  • Aluminium mesh grille
  • Mount with weatherproof treatment
  • Stainless steel screws
• Switch: W selector in high Z and low Z
• Connectors: Euroblock in and out for cable 0.25 – 2.5 mm² cross section
• Temperature Range: -10ºC ~ 60ºC
• Colour: Black (RAL 9005) or White (RAL 9003)
• Dimensions:
  • Loudspeaker: 125 x 202 x 125 mm depth
  • Mount wall plate: 68 x 110 mm
  • Loudspeaker with mount: 193 mm depth
• Weight: 1.5 kg
• Accessories:
  • Adjustable mounting bracket ± 60º in all directions.
  • Steel safety cable

Speaker cable

Mercury oval 100m 6A 100v line speaker cable

Available in:

• Black 100m (804.314)
• White 100m (804.311)

Oval profile mains electric cable. Flexible PVC sheath for use in light electrical applications. BSI approved to BS6500, VDE approved.

• CSA: 0.75mm²
• Strands: 2 x 24/0.2mmØ
• Cable dims: 3.6 x 5.9mm
• Current: 6A max.
• Length: 100m

Product styles may vary.

Each speaker must be set to a maximum of 15W. Exceeding this will overload the amplifier. The system’s total capacity is 240W, with a maximum of 120W per zone.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Fonestar Background Music Sound System appeared first on Sound Services.

Fonestar’s AIP platform integrates seamlessly with modern IT infrastructure, making it suitable for a wide range of environments — from educational institutions and healthcare facilities to offices, transport hubs, and public spaces.

Why Choose Audio over IP?

• Unlimited Channels & Zones – Every area can have its own audio, with stereo or mono feeds tailored per zone.
• Low Bandwidth, High Efficiency – Multicast-ready with minimal network resource use, ensuring no interference with other devices.
• Ultra-Low Latency – Real-time audio playback that’s perfectly synchronised across the system.
• Flexible Configuration – Integrate various sources: background music, alerts, SIP calls, scheduled announcements, and more.
• Smart Monitoring – Detects faults, disconnects, or malfunctions in under 30 seconds.
• Zero Licensing Costs – Free control software and firmware updates included.

Intuitive System Management

Manage your entire audio system from any browser-enabled device — mobile, tablet, or computer:

• Stream audio from any PC or online source
• Send scheduled or live voice announcements
• Adjust volume based on zone, time, or ambient noise
• Assign unique audio feeds to different rooms or buildings
• Make announcements using SIP phones or desk microphones

System Compatibility & Synchronisation

Fonestar’s AIP systems are engineered with compatibility and synchronisation at their core:

• Built on TCP/IP Standards – Easily integrates with standard LAN/VLAN infrastructure
• SIP Support – Fully compatible with third-party SIP servers, phones, and devices
• Synchronised Playback – Time-aligned audio delivery across all devices
• Smart Expansion – Newly added hardware is auto-detected and synchronised without manual intervention
• Flexible I/O Integration – Interface with alarms, door controls, lighting systems, and more using AIP IO modules

Flexible Integration Options

We offer solutions tailored to your level of complexity and system environment:

Basic Integration

• Convert analogue audio to IP using AIP STREAMER
• Integrate alarms, automation, and building systems using AIP IO modules

SIP Integration

• Use SIP phones and devices to trigger audio across zones
• Compatible with external SIP servers or Fonestar’s built-in SIP server (AIP GATE)
• Devices like AIP PLAYER and SONORA-5AIPN include built-in SIP clients

Advanced Integration

• Develop custom solutions using Fonestar’s SDK (C++/.NET)
• Full control via RESTful API (available through AIP GATE)

Suitable for Any Sector

Our AIP solutions are ideal for:

• Education – Multi-zone paging, music, and automated bell schedules
• Healthcare – Zoned paging and quiet background audio
• Retail & Hospitality – Custom ambience and announcements per area
• Offices – SIP intercom and background audio
• Transport & Industry – Site-wide coverage with network efficiency
• Public Sector – Integrated emergency alerts and automation

Get a Bespoke Quotation

Due to the broad capabilities and configuration options of Fonestar’s AIP systems, we offer fully tailored quotations.

Contact us today to discuss your requirements, and we’ll provide a bespoke proposal suited to your building, network, and goals — with no obligation.

The post Fonestar Audio Over IP Systems appeared first on Sound Services.

Samson presents the USB studio condenser microphone that started it all: The C01U.
This classic USB microphone bridges the gap between mid-level USB audio adapters and pro-line products that require additional drivers, special software, and/or excess cabling. The C01U is USB compatible with any Mac or PC, as well as most DAW software programs, including GarageBand. It also comes with Cakewalk’s Sonar LE digital audio workstation software. Its supreme ability to produce pristine audio recordings with ease and moblity, along with a desktop mic stand, mic clip, USB cable and carry pouch also included, makes the C01U a most valueable addition to any studio.
Once drawing inspiration from the wildly successful C01 unit, the C01U is now the foundation and best-seller of Samson’s extensive line of USB microphones. The C01U features a large 19mm shockmounted diaphragm efficient in reproducing both low- and high-volume sounds with equal articulation. The cardioid pickup pattern provides a smooth, flat frequency response. Capturing audio at 16-bit resolution up to a 48kHz sampling rate, the C01U offers the accuracy you need to be sure that what you hear is what you get.
The C01U is essential for any level of musician, but its versatility can be applied to create audio solutions for anyone who records audio, particularly podcasters, educators, and business professionals.

Music Manager

For musicians, the convergence of computer and audio technologies has established the home/mobile studio as an alternative to the professional recording facility. Whether you’re touring the country or experimenting in your project studio, the C01U sets the standard for integrating your computer into your recording experience. Use the cardioid pickup pattern to record vocals or close-mic an acoustic instrument at a pro-level directly to your computer. The C01U is perfect for recording music on-the-go or in limited spaces, allowing all musicians tremendous freedom to create.

Podcaster’s Producer

The evolution of podcasting has created a need for high-quality production capabilities that are also attainable by everyone. Satisfying these criteria, the C01U is a podcaster’s dream come true. Given a simple USB connection straight into your computer, it provides your podcasts with unparalleled quality in audio recording. With the C01U affordable for all, the voices of web journalists are empowered to establish a real identity in the congested world of podcasting.

Academic Advisor

With computer-based technology becoming more steadily incorporated into educational protocols, useful functions for the C01U among students, professors and administrators are also on the rise. In addition to podcasting, the C01U can expand the educational applications for Skype, VoIP, screen capture software like Camtasia Studio and voice recognition software like Dragon Naturally Speaking. These applications, all of which can be used to teach, study or catalogue academic materials, are made easy with the superior degree of audio recording delivered by the C01U. So, whether you’re teaching an online course, reviewing a past lecture or studying for a big exam across multiple computers, the C01U helps to make education a more accessible and interactive experience.

Business Partner

The C01U provides answers for those business professionals in need of revitalizing their corporate communications. Ideal for rich media on websites, in multimedia presentations, company meetings or corporate events, the C01U’s features allow for easy, cost-effective recording of studio-quality audio clips to make your communications more impactful and your presentations come to life. The mobility factor surrounding the C01U is also attractive to business professionals, as it can travel with you as easy as a laptop or briefcase to that next meeting.

Loves to Accessorize

Samson offers a collection of pro-level accessories (all sold separately) that can be used to further enhance the recording experience of the C01U, including the PS01 microphone pop filter and the SP01 spider mount. The PS01’s nylon mesh screen will reduce vocal popping and sibilance from affecting the performance of your C01U. It also comes equipped with a universal mic stand mounting bracket and a flexible metal gooseneck for convenient placement. Lastly, the SP01 provides the C01U with a reliable shockmount system to absorb unwanted vibrations and disturbances.

• Plug in and start recording. No extra gear needed!
• Everything you need for recording audio on a computer
• 16-Bit resolution, 44.1-48kHz sampling
• Cardioid pickup pattern
• Large 19mm diaphragm
• Smooth, flat frequency response
• Includes desktop mic stand, mic clip, USB cable and carry pouch
• Includes Cakewalk Recording Software for your PC: Sonar LE
• Weight: 0.8kg

Musicians, podcasters, educators, business people and many more applicable users can continue to rely on Samson to provide the highest standard of simple, affordable and mobile USB studio condenser microphone technology: The C01U.

All used and ex-display items are tried and tested before leaving our warehouse, but will have usage marks and some signs of wear – used, ex-display and clearance items include a 90 day return-to-base warranty.

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

The post Samson C01U Studio Microphone – Used appeared first on Sound Services.
